Schneider Electric Easy9 RCCB | 2 Pole, 40A, 30mA (AC Type) | Instantaneous Earth Leakage Protection | Essential Safety for Home & Residential Electrical Circuits (EZ9R35240)

Prioritize unparalleled electrical safety in your home and safeguard against dangerous electric shocks with the Schneider Electric Easy9 Residual Current Circuit Breaker (RCCB). Designed for robust performance in residential and light commercial applications, this 2-pole, 40A RCCB delivers instantaneous earth leakage protection at a life-saving 30mA (AC type). Trust in Schneider Electric's established reputation for quality and innovation to protect your family and property from fault currents.

Key Features & Benefits:

• Crucial Life Safety Protection: Instantly cuts off power at 30mA earth-leakage current, providing vital protection against electric shock and preventing electrical fires caused by insulation faults.
• Reliable AC Type for General Use: Specifically engineered to detect alternating sinusoidal residual currents, making it perfectly suited for most standard household and residential electrical installations.
• High Breaking Capacity: Ensures effective and safe interruption of fault currents with a strong rated breaking and making capacity of 500A.
• Built for Durability: Constructed for long-term reliability with 5000 mechanical cycles and 4000 electrical cycles, promising dependable operation for years.
• Effortless DIN Rail Installation: Features a convenient clip-on mounting mechanism for quick and secure attachment to standard DIN rails within your distribution board.
• Versatile Wiring: Equipped with tunnel type terminals (top or bottom) that accommodate both rigid (1-35mm²) and flexible (1-25mm²) cables for adaptable connections.
• Clear Contact Position Indicator: Provides an immediate visual indication of the breaker's current operational status (ON/OFF).
• Voltage Independent Tripping: Maintains consistent and reliable protection by tripping effectively even during fluctuations in the main voltage supply.
• Compact & Space-Saving: Its slim 36mm width (2-pole) optimizes space within your electrical panel.
• Certified for India: Compliant with IS 12640-1 and IEC 61008-1 standards, and proudly carries ISI and CE certifications, guaranteeing compliance and safety for the Indian market.

Technical Specifications:

• Brand: Schneider Electric
• Range: Easy9
• Product Type: Residual Current Circuit Breaker (RCCB)
• Model Number: EZ9R35240
• Poles: 2P (2 Pole)
• Neutral Position: Left
• Rated Current (In): 40 A
• Network Type: AC
• Earth-Leakage Sensitivity: 30 mA
• Earth-Leakage Protection Time Delay: Instantaneous
• Earth-Leakage Protection Class: Type AC
• Rated Breaking & Making Capacity: 500 A
• Rated Conditional Short-Circuit Current: 3000 A (at 40A)
• Rated Operational Voltage (Ue): 240 V AC 50 Hz
• Rated Insulation Voltage (Ui): 440 V AC
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Control Type: Toggle
• Mounting Mode: Clip-on
• Mounting Support: DIN rail
• Connection Terminals: Tunnel type terminal (top or bottom)
  • 1…35 mm² rigid cable
  • 1…25 mm² flexible cable
• Dimensions (H x W x D): 82 mm x 36 mm x 77.5 mm
• Product Weight: 0.215 kg
• Colour: Grey (RAL 7035)
• Mechanical Durability: 5000 cycles
• Electrical Durability: 4000 cycles (at 240 V AC 50 Hz)
• Standards: IS 12640-1, IEC 61008-1
• Certifications: ISI, CE
• IP Degree of Protection: IP20
• Ambient Air Temperature for Operation: -5…55 °C
• Targeted Country: India

Secure your electrical installations against critical fault currents and ensure maximum human safety. Add the Schneider Electric Easy9 2P 40A 30mA AC Type RCCB to your cart today for ultimate peace of mind!
